HSMAG's people's constant mission is to create excellence jointly HSMAG focus on product in detail to make our ideal true HSMAG pursues continous perfection to satisfy our customer at maximum
4 Years
| Ask Lasest Price | |
| Brand Name : | HSMAG |
| Model Number : | SmCo |
| Certification : | ITAF16949 ISO9001 |
| Supply Ability : | 1000PCS 20Days |
| Delivery Time : | 20work days |
China Supplier Stainless Steel And Magnet Drive Magnetic Shaft Coupling For Motor Pump
The Main Products
SmCo (Samarium Cobalt) permanent magnet
Product Paramenters
The components of samarium and cobalt?
SmCo Series 1:5
SmCo Series 1:5 has one atom of rare earth samarium and five atoms of cobalt. By weight this magnet alloy will typically contain 36% samarium with the balance cobalt. SmCo magnets generally have a reversible temperature coefficient of -0.05%. The maximum working temperature is about 350 ℃.
SmCo Series 2:17
SmCo Series 2:17 are age-hardened with a composition of two atoms
of rare-earth samarium and 13-17 atoms of transition metals(TM).
The TM content is rich in cobalt, but contains other elements such
as iron and copper.
Other elements like zirconium, hafnium, and such may be added in
small quantities to achieve better heat treatment. By weight, the
alloy
will generally contain 25% of samarium. The maximum energy of these
alloys ranges from 24 to 30 MGOe. SmCo magnets generally have
a reversible temperature coefficient of -0.03% ℃. The maximum
working temprature is 350℃
1:5 SmCo Magnet SmCo5(25 MGOe) | SmCo1:5 Magnet is also called SmCo5, the highest working enviorment can be 250℃.Based on Sm,Co and some other metals. After processing of melting, milling, compression moulding and sintering. To make work blank with different levels of performance |
2:17 SmCo Magne Sm2Co17 (32 MGOe) | SmCo2:17 Magnet is also called Sm2Co17, the highest working can be 350℃.Based on Sm, Co, copper, iron zirconium and some other metals. After processing of melting, milling, compression moulding and sintering. To make work blank with different levels of performance. |
Company Profile
Mianyang Hengxin Magnetic Materials Co., Ltd. was founded in 1999, specializing in the manufacture and development of sintered samarium cobalt permanent magnet materials and devices; after years of development, it has formed a production capacity of 500 tons of samarium cobalt permanent magnet materials per year, and is the main manufacturer of samarium cobalt permanent magnet materials and devices in China.
