HSMAG's people's constant mission is to create excellence jointly HSMAG focus on product in detail to make our ideal true HSMAG pursues continous perfection to satisfy our customer at maximum
4 Years
| Ask Lasest Price | |
| Brand Name : | HSMAG |
| Model Number : | Sm2Co17 |
| Certification : | ITAF16949 |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 100000PCS 15Days |
| Delivery Time : | 15 work days |
SmCo1:5 Magnet is also called SmCo5, the highest working can be 250℃.Based on Sm,Co and some other metals. After processing of melting, milling, compression moulding and sintering. To make work blank with different levels of performance.
SmCo2:17 Magnet is also called Sm2Co17, the highest working can be 350℃.Based on Sm, Co, copper, iron zirconium and some other metals. After processing of melting, milling, compression moulding and sintering. To make work blank with different levels of performance.
| Surface | Method | Thickness | Colour |
| Ni | Electroplate | 10 | Silver Semi-bright |
| Zn | Electroplate | 10 | Silver Semi-bright |
| Ni-Cu-Ni | Electroplate | 10 | Silver Semi-bright |
| Ni+Sn | Electroplate | Ni 5 Sn 10 | Silver Semi-bright |
| Aluminum Chromate | Lon-deposition | 5 | Yellow Semi-bright |
| Resin Coatings | Spray Painting Electrophoresis | 20 | Black |
SmCo5 magnet is composed of SmCo alloy with SM CO ratio of 1-5, that is, one SM atom and five co atoms. According to weight, SM accounts for 36% of the total. This SmCo alloy usually contains 36% SM and a small amount of Co. this series of SmCo magnets can provide a maximum magnetic energy product of 25mgoe and a reversible temperature coefficient of - 0.05% / ℃. In addition, this series is easier to calibrate to a specific magnetic field than Sm2Co17 series. The Sm2Co17 magnet consists of SmCo alloy with a SmCo ratio of 2:17, i.e. 2 SM atoms and 17 co atoms. It also contains other elements, such as iron, copper, zirconium and hafnium, but the amount is very small. The magnetic energy product of this property is higher, up to 32 mgoe, and the reversible temperature coefficient is - 0.03% / ℃.
The specific proportion is SM: 23-28%; Rare earth metal cobalt: 48-52%; Metallic element Fe: 14-17%; Metal element Cu: 5-7%; A small amount of Zr: 2-3 was added.
Mianyang Hengxin Magnetic Materials Co., Ltd. was founded in 1999,
specializing in the manufacture and development of sintered
samarium cobalt permanent magnet materials and devices; after years of development, it has formed a production capacity of
500 tons of samarium cobalt permanent magnet materials per year,
and is the main manufacturer of samarium cobalt permanent magnet
materials and devices in China.
|
|
