| Brand Name : | HSMAG |
| Model Number : | Sm2Co17 |
| Certification : | ITAF16949 |
| Payment Terms : | L/C, D/A, D/P, T/T |
| Supply Ability : | 1000PCS 10Days |
| Delivery Time : | 15 work days |
Sintered Industrial Arc SmCo Magnet Electroplate Ni/Zn/Epoxy Coated High Temp Resist
Product Paramenters
Application
1). Electronics – Sensors, hard disk drives, sophisticated
switches, electro-mechanical devices etc.;
2). Auto Industry – DC motors (hybrid and electric), small
high-performance motors, power steering;
3). Medical – MRI equipment and scanners;
4). Clean Tech Energy – Water flow enhancement, wind turbines;
5). Magnetic Separators – Used for recycling, food and liquids QC,
waste removal;
6). Magnetic Bearing – Used for highly sensitive and delicate
procedures in various heavy industries.
The components of Samarium and Cobalt?
SmCo5 magnet is composed of SmCo alloy with Sm Co ratio of 1:5. According to weight, Sm accounts for 36% of the total. This SmCo alloy usually contains 36% Sm and a small amount of Co. This series of SmCo magnets can provide a maximum magnetic energy product of 25 MGOe and a reversible temperature coefficient of - 0.05% / ℃. In addition, this series is easier to calibrate to a specific magnetic field than Sm2Co17 series. The Sm2Co17 magnet consists of SmCo alloy with a SmCo ratio of 2:17. It also contains other elements, such as iron, copper, zirconium and hafnium in a small amount. The magnetic energy product of this property is higher, up to 32 MGOe, and the reversible temperature coefficient is - 0.03% / ℃.
The specific proportion is Sm: 23-28%; Rare earth metal Cobalt: 48-52%; Metallic element Fe: 14-17%; Metal element Cu: 5-7%; A small amount of Zr: 2-3 was added.
| Sm | 23-28% |
| Co | 48-52% |
| Fe | 14-17% |
| Cu | 5-7% |
| Zr | 2-3% |
